Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork Suntour MOBIE -
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Power Tube 800 Horizontal -
Drivetrain 1 × 10 -
Brakes Magura Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec EP Life Belt 27.5“ Aluminium 12x148mm
Suspension Fork
SR SUNTOUR MOBIE34-D ABS EQ 2CR 27.5“
Drivetrain
Rear Derailleur
SHIMANO RD-U6020-10 CUES SGS 10-SPEED
Shift Levers
SHIMANO SL-U6000-10R CUES 10-SPEED
Cassette
SHIMANO CS-LG300-10 CUES 10-SPEED 11-39T
Crank
MIRANDA DM CF3D 38T
Chain
SHIMANO CN-LG500 LINKGLIDE 9/10/11 SPEED
Wheels
Rims
584-25 15x110 front , 584-25 12x148 rear
Tires
SCHWALBE JOHNNY WATTS 60-584 front , SCHWALBE JOHNNY WATTS 60-584 rear
Brakes
Brakes
MAGURA MT C ALLROAD ABS 4 Piston 203mm front , MAGURA MT C ALLROAD ABS 4 Piston 180mm rear
Cockpit
Stem
ERGOTEC Swell RE 31.8 80/100mm
Handlebar
ERGOTEC Riser Bar 50 31.8mm 720mm 25 Deg Backsweep
Seat
Saddle
SQ Lab 621 ERGOLUX
Seatpost
ERGOTEC Ray 31.6mm
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Power Tube 800 Horizontal
