Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 100mm -
Fork RockShox SID Select
-
Groupset XX Eagle Transmission, X0 Eagle Transmission -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Level Silver Stealth Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec Revo Bow iLink Carbon 29“ 100mm Travel 12x148mm
Suspension Fork
ROCK SHOX SID SELECT 3 POS 29“ 15x110 120mm
Drivetrain
Rear Derailleur
SRAM X0 EAGLE AXS T-TYPE 12-SPEED
Shift Levers
SRAM AXS POD
Cassette
SRAM CS XS 1275 T-TYPE 10-52T
Crank
SRAM XX EAGLE Q174 CL55 DUB 170 34 T-TYPE
Chain
SRAM GXT-TYPE
Wheels
Rims
DT SWISS XMC 1501 SPLINE® 29“ 30 mm CL Tubeless XD front , DT SWISS XMC 1501 SPLINE® 29“ 30 mm CL Tubeless XD rear
Tires
Schwalbe RACING RAY Evo 60-622 front , Schwalbe RACING RALPH Evo 60-622 rear
Brakes
Brakes
SRAM LEVEL SILVER STEALTH 4-Piston 180mm front , SRAM LEVEL SILVER STEALTH 4-Piston 160mm rear
Cockpit
Stem
URSUS MAGNUS HX.01 MTB integrated 65/75mm
Handlebar
URSUS MAGNUS HX.01 MTB integrated 760mm
Seat
Saddle
SELLE ITALIA FLITE BOOST SUPERFLOW Manganese
Seatpost
KS LEV-Integra 31.6 125mm
