Cotic Cascade Drop Bar / Gold Shimano GRX820 12spd 2024
2024 Road
Estimate price |
3,725$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 167cm
SM
164cm - 174cm
MD
172cm - 180cm
LG
178cm - 188cm
XL
186cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano GRX 1x12, 10-51 Cassette, Hydraulic Disc Brakes
Crank
Easton EA90 36t Boost Chainset 172.5
Bottom Bracket
RaceFace 30mm BB
Wheels
Rims
Shimano MT620 Wheels Boost 29 12spd
Tires
WTB Ranger 29x2.4 Light Tanwall with tubeless kit
Brakes
Brakes
Pair of Shimano rotors 180/160 centerlock for direct mount
Cockpit
Stem
Cotic 60mm Stem, 31.8 Clamp
Handlebar
Cotic Valley Bars - 46cm Alu Flared Drop
Headset
Hope 1H for taper steerer (black)
Seat
Seatpost
BikeYoke Seatpost 125mm drop for Cascade
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.641 mm | 1.557 mm | 1.515 mm | 1.465 mm | 1.421 mm |
| Front Center | 643 mm | 663 mm | 680 mm | 707 mm | 733 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 85 mm | 85 mm | 79 mm | 78 mm | 79 mm |
| Stack | 604 mm | 604 mm | 621 mm | 633 mm | 645 mm |
| Reach | 368 mm | 388 mm | 410 mm | 432 mm | 454 mm |
| Top Tube Length | 541 mm | 561 mm | 588 mm | 613 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 435 mm | 470 mm | 505 mm | 540 mm |
| Head Tube Angle | 68 ° | 68 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 113 mm | 126 mm | 139 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1072 mm | 1092 mm | 1109 mm | 1136 mm | 1162 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 164 cm | 172 cm | 178 cm | 186 cm |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 188 cm | 195 cm |
