Cotic Solaris Downcountry / Gold GX Eagle 2024
2024 Mountain
Estimate price |
5,215$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
C1
162cm - 172cm
C2
170cm - 178cm
C3
176cm - 184cm
C4
182cm - 190cm
C5
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Rock Shox SID Ultimate 120mm Black
Drivetrain
Rear Derailleur
SRAM GX Eagle Lunar 1x12 Drivetrain
Cassette
EAGLE GX 12spd 10-52 Cassette
Bottom Bracket
SRAM DUB BB for DUB Cranks - BBDUB5000
Wheels
Rims
Hope Fortus26 29 XD (black Pro5 hubs)
Tires
Maxxis EXO Forekaster + Rekon 29x2.4 MaxxTerra
Brakes
Brakes
Pair of SRAM Guide rotors 180/180 6bolt
Cockpit
Stem
Cotic SHORTERSTEM - 35mm
Handlebar
Cotic Calver Bars - 780 x 25 rise, 5deg up, 9deg back (black)
Headset
Hope 2H for tapered steerer (black)
Seat
Seatpost
SDG Tellis V2 31.6 Seatpost 170mm drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | C1 | C2 | C3 | C4 | C5 |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.395 mm | 1.36 mm | 1.329 mm | 1.299 mm | 1.253 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 731 mm | 753 mm | 775 mm | 797 mm | 815 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 119 mm | 119 mm | 119 mm | 119 mm | 119 mm |
| Stack | 611 mm | 620 mm | 630 mm | 639 mm | 639 mm |
| Reach | 438 mm | 456 mm | 474 mm | 492 mm | 510 mm |
| Top Tube Length | 602 mm | 622 mm | 643 mm | 663 mm | 681 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 390 mm | 417 mm | 444 mm | 471 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 130 mm |
| Chainstay Length | 444 mm | 444 mm | 444 mm | 444 mm | 444 mm |
| Wheelbase | 1166 mm | 1188 mm | 1210 mm | 1232 mm | 1250 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 170 cm | 176 cm | 182 cm | 184 cm |
| Rider Max Height | 172 cm | 178 cm | 184 cm | 190 cm | 195 cm |
