Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Nexus -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
tig welded cromoly steel frame tig welded cromoly steel frame cromoly steel double butted frame
Suspension Fork
cromoly steel fork, lugged, 1", with invest cast crown cromoly steel fork, lugged, 1", with invest cast crown cromoly steel fork, lugged, 1", with invest cast crown
Drivetrain
Shift Levers
Shimano Nexus 7 speed revo shifter Shimano Nexus 7 speed revo shifter Shimano Nexus 7 speed trigger shifter
Crank
aluminium, 170mm, 44t ring Creme classic cranks, high polish finish aluminium, 170 mm, 44t ring Creme classic cranks, high polish finish aluminium, 170 mm, 44t ring
Bottom Bracket
square taper, 68mm shell square taper, 68mm shell square taper, 68mm shell
Pedals
FP-980AZU / FP-920B* FP-980AZU / FP-920B* FP-980AZU
Wheels
Front Hub
aluminium sealed bearings, 36, track nuts Shimano Dynamo, 36H Shimano Dynamo, 36H
Rear Hub
Shimano Nexus SGC30007C 7-speed hub with frewheel, 36H, sprocket
Rims
aluminium doublewall 700C, silver polished aluminium doublewall 700C, silver polished aluminium doublewall 700C, silver polished
Spokes
stainless steel stainless steel
Tires
Innova 37-622, 700x35C / Excel 37-622, 700X35C Panaracer GravelKing Sport, 700x35C, Schwalbe Delta Cruiser 700x35C Continental GP Urban, 35-622
Brakes
Brakes
Promax caliper, dual pivot Promax caliper, dual pivot Promax caliper, dual pivot
Cockpit
Stem
Creme custom aluminium a-head stem, ext 80mm, rise 15 deg, polished Creme custom aluminium a-head stem, ext 80mm, rise 15 deg, polished aluminium melt forged quill stem, 80mm, high polish, L 150mm
Handlebar
“albatros” type, aluminium, width
Grips
Creme Gummy Grips Creme Gummy Grips with alloy bar-ends Brooks B17 grips
Headset
threadless 1'' threadless 1'' threaded, 1”
Seat
Saddle
Creme man / Creme* Brooks Cambium Brooks Cambium
Seatpost
aluminium, 26,0mm aluminium, 26,0mm aluminium, 27,2mm
Fit data
Geometry
