Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Nexus, Gates CDX -
Suspension Rigid -
Motor Shimano 250W 40Nm mid-drive -
Battery Battery 504 Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
aluminium frame
Suspension Fork
cromoly steel fork, lugged, 1 1/8" with invest cast crown, 12mm through axle
Drivetrain
Shift Levers
Shimano Nexus 5 speed revo shifter
Crank
Creme aluminium crank, 170 mm, 42t Gates CDX chainring
Bottom Bracket
integrated with Shimano STEPS
Pedals
FP-920B
Wheels
Front Hub
aluminium, sealed bearings, 32h, centerlock, for 12mm through axle
Rear Hub
Shimano Nexus SG-C7000-5D 5-speed hub, 36H, 32t Gates CDX sprocket
Rims
disc brake, aluminium, double wall
Spokes
stainless steel
Tires
Schwalbe Fat Frank, 50-622, 28X2.00
Brakes
Brakes
Tektro M280, mechanical disc brake with 160 mm rotor
Cockpit
Stem
aluminium adjustable a-head stem, 90mm
Handlebar
“albatros” type, aluminium, width
Grips
Creme Gummy Grips with alloy bar-ends
Headset
threadless 1 1 /8''
Seat
Saddle
Creme
Seatpost
Aluminium, 27.2mm
Motor & Battery
Motor
Electric Drive Shimano STEPS E5000
Battery
Battery 504 Wh
Fit data
Geometry
