Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
cromoly steel double butted frame with cast dropouts, Tange seat-tube clamp
Suspension Fork
cromoly steel fork, lugged, 1 1/8" with invest cast crown, 12mm through axle
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700
Front Derailleur
Shimano Tiagra FD-4700
Shift Levers
Shimano Tiagra ST-4700
Cassette
Shimano CS-HG500 11-34 10 speed
Crank
Creme custom 50/34 integrated axle
Bottom Bracket
integrated
Pedals
FP-980AZU
Wheels
Front Hub
aluminium, sealed bearings, 32h, centerlock, for 12mm through axle
Rear Hub
aluminium, sealed bearings, 32h, centerlock, for 12mm through axle
Rims
disc brake, aluminium, double wall
Spokes
stainless steel
Tires
WTB Horizon 47-584, 650Bx47
Brakes
Brakes
Shimano ST-R7020 105 hydraulic disc wtih 160 mm rotor
Cockpit
Stem
aluminium a-head stem, extension 90mm, rise 7, 90mm for S, 100mm for M and L, 110mm for XL
Handlebar
aluminium, width
Grips
Brooks Cambium bar tape
Headset
threadless 1 1 /8''
Seat
Saddle
Brooks Cambium
Seatpost
Aluminium, 27.2mm
Fit data
Geometry
