Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
cromoly steel double butted frame with cast dropouts, Tange seat-tube clamp
Suspension Fork
cromoly steel fork, lugged, 1 1/8" with invest cast crown, 12mm through axle
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000
Front Derailleur
Shimano 105 FD-R7000
Shift Levers
Shimano 105 ST-R505
Cassette
Shimano CS-R7000 11-30 11 speed
Crank
Creme custom 50/34 integrated axle
Bottom Bracket
integrated
Pedals
FP-980AZU
Wheels
Front Hub
Shimano Dynamo, centerlock, for 12mm through axle, 32H
Rear Hub
aluminium, sealed bearings, 32h, centerlock, for 12mm through axle
Rims
disc brake, aluminium, double wall
Spokes
stainless steel
Tires
WTB Horizon 47-584, 650Bx47
Brakes
Brakes
Shimano ST-R7020 105 hydraulic disc wtih 160 mm rotor
Cockpit
Stem
aluminium a-head stem, extension 90mm, rise 7, 90mm for S, 100mm for M and L, 110mm for XL
Handlebar
aluminium, width
Grips
Brooks Cambium bar tape
Headset
threadless 1 1 /8''
Seat
Saddle
Brooks Cambium
Seatpost
Aluminium, 27.2mm
Fit data
Geometry
