Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Alfine, Gates CDX -
Suspension Rigid -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
tig welded cromoly steel frame
Suspension Fork
aluminium fork 1 1/8", 12mm through axle
Drivetrain
Shift Levers
Shimano Alfine 8 speed trigger shifter
Crank
Creme aluminium crank, 170 mm, 46t Gates CDX chainring
Bottom Bracket
integrated
Pedals
FP 212
Wheels
Front Hub
Shimano Dynamo, centerlock, for 12mm through axle, 32H
Rear Hub
Shimano Alfine SG-S7001-8, 8-speed hub, 32H, Gates CDN 24t sprocket
Rims
disc brake, aluminium, double wall
Spokes
stainless steel
Tires
Continental GP Urban, 35-622
Brakes
Brakes
Shimano Mt-200 hydraulic disc brakes with 160 mm rotor
Cockpit
Stem
aluminium adjustable a-head stem, 90mm for size S, 110mm for size M and L
Handlebar
“banana” type, aluminium, width
Grips
Creme Gummy Grips with alloy bar-ends
Headset
threadless 1 1 /8''
Seat
Saddle
Brooks Cambium
Seatpost
aluminium, 26,6mm
Fit data
Geometry
