Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset CUES, Shimano -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
155cm - 175cm
LG
170cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18")
Suspension Fork
Suntour XCR 32, AIR, RLR DS 100mm 29"
Drivetrain
Rear Derailleur
Shimano CUES RD-U6000
Shift Levers
Shimano CUES SL-U6000/10 sp.
Crank
Shimano CUES FC-U4000-1, 32T/170mm
Chain
Shimano CN-LG500
Pedals
SP 510
Wheels
Rear Hub
CTM alloy center-lock 32H QR black
Rims
CTM TOP DISC, 622x19 BA, 32H
Tires
WTB Ranger 29x2.25" Comp
Brakes
Brakes
Shimano MT200 / SMRT10
Cockpit
Stem
CTM LCS 50/31.8 mm
Handlebar
CTM XC Rise bar, 700/31.8 mm
Headset
NECO H156
Seat
Saddle
SR Vivo Ergo Lady
Seatpost
CTM SPDC1, 350x31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.517 mm | 1.474 mm |
| Front Center | 683.5 mm | 704.5 mm |
| Rake | 46 mm | 46 mm |
| Stack | 622 mm | 631 mm |
| Reach | 410 mm | 428 mm |
| Top Tube Length | 595 mm | 615 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 405 mm | 455 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1121 mm | 1142 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 155 cm | 170 cm |
| Rider Max Height | 175 cm | 190 cm |
