Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061 double butted, 520, 540, 560, 580, 600mm
Suspension Fork
Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX822
Shift Levers
Shimano GRX / RX-610 12s.
Crank
Shimano GRX FC-RX610-1, 40T, 520/170mm, 540/172.5mm, 560,580,600/175mm
Chain
Shimano CN-M6100
Wheels
Rear Hub
Novatec 25, F/R 12mm thru type axle
Rims
Novatec 25 F/R
Tires
WTB Riddler TCS light, 700x37c
Brakes
Brakes
Shimano GRX RX400/SMRT64 S
Cockpit
Stem
CTM TDS-RD701 80mm
Handlebar
FSA A-Wing bars 440mm
Headset
FSA Orbit C40, ACB
Seat
Saddle
PHYSICS Terra Argo X5
Seatpost
CTM SPDC1 350/400x27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.532 mm | 1.466 mm | 1.451 mm | 1.457 mm | 1.422 mm |
| Front Center | 600 mm | 610 mm | 623 mm | 646 mm | 667 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Stack | 553 mm | 557 mm | 566 mm | 590 mm | 600 mm |
| Reach | 361 mm | 380 mm | 390 mm | 405 mm | 422 mm |
| Top Tube Length | 525 mm | 545 mm | 558 mm | 580 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 500 mm | 540 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 73 ° | 74 ° |
| Head Tube Length | 140 mm | 140 mm | 150 mm | 175 mm | 185 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1020 mm | 1030 mm | 1044 mm | 1067 mm | 1088 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
