Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork Suntour NEX -
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
MD
150cm - 166cm
LG
164cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18")
Suspension Fork
Suntour NEX, HLO, DS, 700C
Drivetrain
Rear Derailleur
Shimano RD-TY500
Shift Levers
Shimano STEF5002/7 sp.
Crank
Shimano FC-TY301, 48-38-28T, 175mm
Chain
KMC Z50
Pedals
SP 877
Wheels
Rear Hub
CTM alloy 6 bolt 32H QR black
Rims
CTM TOP DISC, 622x19 BA, 32H
Tires
28x1.75 reflex stripe
Brakes
Brakes
Hayes mechanical disc brake
Cockpit
Stem
CTM adjustable, 90/25.4 mm
Handlebar
Zoom MTB-153, 620/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
Zoom C208, 300/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm |
| Rider Max Height | 166 cm | 180 cm |
