Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork Suntour XCM
-
Groupset CUES -
Suspension Hardtail -
Motor Bafang 250W 95Nm mid-drive -
Battery CTM IGB 672Wh / 48V / 14Ah -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18")
Suspension Fork
Suntour XCM32 ATB, UFO, DS, 80mm
Drivetrain
Rear Derailleur
Shimano CUES RD-U4000
Shift Levers
Shimano CUES SL-U4000/9sp.
Crank
Lasco, 42T, 170mm
Chain
KMC X9e
Pedals
VP 613
Wheels
Rear Hub
Novatec D041DSB/D142TSE,36H,CL
Rims
WTB ST i23 TCS 2.0 29" 36H
Tires
WTB Cruz 29x2.0" Comp
Brakes
Brakes
Shimano MT200 / SMRT10M
Cockpit
Stem
CTM UP2/90mm
Handlebar
CTM rise bar, 660/31.8 mm
Headset
NECO H156
Seat
Saddle
CTM
Seatpost
CTM 350x31.6 mm
Motor & Battery
Motor
BAFANG M500 / 250W / 95Nm
Battery
CTM IGB 672Wh / 48V / 14Ah
Fit data
Geometry
