Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset CUES, Shimano -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (18"), L (20"), XL (22")
Suspension Fork
Suntour XCR32, AIR, RLR, DS, 100mm
Drivetrain
Rear Derailleur
Shimano CUES RD-U6000
Shift Levers
Shimano CUES SL-U6000/11sp.
Crank
Shimano CUES FC-U6000-1, 32T/175mm
Chain
Shimano CN-LG500
Pedals
VPE 461
Wheels
Rear Hub
Shimano QC-300 center-lock 32H
Rims
CTM TOP DISC, 622x19 BA, 32H
Tires
WTB Ranger 29x2.25" Comp
Brakes
Brakes
Shimano MT200 / SMRT10 S/M
Cockpit
Stem
CTM LCS 80/31.8 mm
Handlebar
CTM rise bar, 720/31.8 mm
Headset
NECO H156
Seat
Saddle
CTM
Seatpost
CTM SPDC1, 350x31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.424 mm | 1.377 mm |
| Front Center | 698.5 mm | 719.5 mm | 745 mm |
| Rake | 46 mm | 46 mm | 46 mm |
| Stack | 622 mm | 631 mm | 640.5 mm |
| Reach | 426 mm | 443 mm | 465 mm |
| Top Tube Length | 610 mm | 630 mm | 655 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 470 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1136 mm | 1157 mm | 1183 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
