Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (18"), L (20"), XL (22") triple butted
Suspension Fork
Rock Shox RECON GOLD, DebonAir, 100mm, boost™ 15x110axle
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100/12sp.
Crank
Shimano Deore XT-M8100-1, hollowtech, 32T
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-M6100
Pedals
VPE 461
Wheels
Rear Hub
Shimano TC500, CL, F15/R12 thru type axle
Rims
WTB STi25, TCS, 29", 32H
Tires
WTB Ranger 29x2.25" TCS, light/fast rolling
Brakes
Brakes
Shimano Deore BR-M6100 / SMRT64 S/M
Cockpit
Stem
CTM ASM02 90 mm
Handlebar
CTM HB352, 35dia, 760mm
Headset
FSA Orbit 1.5" tapered
Seat
Saddle
CTM FLAT
Seatpost
CTM SP3D2, 350/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.385 mm | 1.345 mm | 1.308 mm |
| Front Center | 710.5 mm | 734.5 mm | 758 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Stack | 609.5 mm | 618.5 mm | 628 mm |
| Reach | 440 mm | 460 mm | 480 mm |
| Top Tube Length | 603 mm | 625.5 mm | 648.5 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1138 mm | 1162 mm | 1186 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
