Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 50mm -
Fork Suntour XCT
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
24"
125cm - 145cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, 13"
Suspension Fork
Suntour XCT-JRDS 50mm 24"
Drivetrain
Rear Derailleur
Shimano Tourney RD-TY200
Shift Levers
Shimano Altus SL-M315/7 sp.
Crank
Lasco, 34T, 150mm
Chain
KMC Z33
Pedals
VPE 229
Wheels
Rear Hub
CTM alloy 6 bolt 32H QR black
Rims
CTM TOP DISC, 507x19 BA, 32H
Tires
24x1.75"
Brakes
Brakes
Hayes mechanical disc brake
Cockpit
Stem
Zoom 50/25.4 mm
Handlebar
Zoom MTB-153, 600/25.4 mm
Headset
Neco H-148M/B
Seat
Saddle
CTM junior
Seatpost
Zoom SP-102, 300/30.4 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Wheels | 24" |
| Rider Min Height | 125 cm |
| Rider Max Height | 145 cm |
