Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork Suntour NEX -
Groupset CUES, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (17"), L (19"), XL (21")
Suspension Fork
Suntour NEX, HLO, DS, 700C
Drivetrain
Rear Derailleur
Shimano CUES RD-U3020
Shift Levers
Shimano CUES SL-U4000/9sp.
Crank
Shimano CUES FC U4010-2, 46-30T, 175mm
Chain
Shimano CN-LG500
Pedals
SP 510
Wheels
Rear Hub
CTM alloy center-lock 32H QR black
Rims
CTM TOP DISC, 622x19 BA, 32H
Tires
28x1.75 reflex stripe
Brakes
Brakes
Shimano MT200 / SMRT10
Cockpit
Stem
CTM RB11, 90 mm
Handlebar
CTM 640mm
Headset
Something semi-integrated
Seat
Saddle
CTM
Seatpost
CTM SP 350x31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 660 mm | 670 mm | 680 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 602 mm | 612 mm | 622 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 140 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1103 mm | 1114 mm | 1123 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
