Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Fork RockShox Paragon Gold RL -
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 176cm
LG
174cm - 186cm
XL
184cm - 205cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M, L, XL double butted
Suspension Fork
Rock Shox PARAGON GOLD, RL, SA, 29"
Drivetrain
Rear Derailleur
Shimano CUES FD-U6010
Shift Levers
Shimano CUES SL-U6000/11sp.
Crank
Shimano CUES FC U8000-2, 46-32T, 175mm
Chain
KMC XGLIDE
Pedals
VP 461
Wheels
Front Hub
CTM alloy center-lock 32H QR black
Rear Hub
CTM alloy center-lock 32H QR black
Rims
WTB STi23, TCS, 29", 32H
Brakes
Brakes
Shimano MT200 / SMRT10
Cockpit
Handlebar
CTM N04, 700/1" rise/31.8mm
Headset
Something semi-integrated
Seat
Saddle
SR ESSENZA ATHLLETIC
Seatpost
CTM LCSP-53, 350/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Front Center | 660 mm | 670 mm | 680 mm |
| Rake | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 602 mm | 612 mm | 622 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 140 mm | 140 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1103 mm | 1114 mm | 1123 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 174 cm | 184 cm |
| Rider Max Height | 176 cm | 186 cm | 205 cm |
