Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork Suntour XCE
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
MD
150cm - 166cm
LG
164cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, M (16"), L (18")
Suspension Fork
Suntour XCE28, 80mm, 26"
Drivetrain
Rear Derailleur
Shimano RD-TY500
Shift Levers
Shimano STEF5002/7 sp.
Crank
Shimano FC-TY301, 42-34-24T, 170mm
Chain
KMC Z50
Pedals
SP 877
Wheels
Rear Hub
Matrix alloy 32H QR black
Rims
CTM ZX-lite, 559x19 BA, 32H
Tires
CTM SCRATCH 26x2.0"
Brakes
Brakes
Alhonga V-brake
Cockpit
Stem
CTM adjustable, 115/25.4 mm
Handlebar
Zoom MTB-153, 640/25.4 mm
Headset
Something semi-integrated
Seat
Saddle
CTM lady
Seatpost
Zoom C208, 300x30 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 26" | 26" |
| Rider Min Height | 150 cm | 164 cm |
| Rider Max Height | 166 cm | 180 cm |
