Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery SHIMANO BT-E8036 / 630Wh -
Drivetrain 1 × 11 -
Brakes Tektro Orion Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, rear travel 150 mm, MD, LG, XL
Suspension Fork
Rock Shox 35 SILVER TK, SA, 160mm, boost™ 15x110axle
Rear Shock
RockShox Deluxe Select+ RT (205x65)
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100/11sp.
Crank
FSA CK-751, 36T, 165mm
Chain
KMC X11e 122L
Pedals
VPE-527
Wheels
Front Hub
Shimano MT400 boost / 32H
Rear Hub
Shimano MT400 boost / 32H
Rims
WTB ST i35 TCS 2.0 / 27.5'' / 29'' / 32H
Brakes
Brakes
TEKTRO ORION / 203 / DISC
Cockpit
Handlebar
CTM HB352, 35dia, 780mm
Headset
FSA Orbit 1.5
Seat
Saddle
WTB Volt
Seatpost
KS RAGEi (M-125mm/L,XL-150mm)
Motor & Battery
Motor
SHIMANO STEPS E7000 / 250W / 60Nm
Battery
SHIMANO BT-E8036 / 630Wh
Fit data
Geometry
