Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 110mm -
Fork Suntour XCM
-
Groupset CUES, Shimano -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6061, S, M, L, XL
Suspension Fork
Suntour XCM34-boost, 15AH2, LO, DS, 110mm
Drivetrain
Rear Derailleur
Shimano CUES RD-U4000
Shift Levers
Shimano CUES SL-U4000/9sp.
Crank
Shimano CUES FC-U6000-1, 32T/170mm
Chain
Shimano CN-LG500
Pedals
SP 510
Wheels
Rear Hub
Shimano TC500, CL, F15/R12 thru type axle
Rims
WTB STi29, TCS, 27.5", 32H
Tires
WTB Trail Boss 27.5x2.25 " Comp
Brakes
Brakes
Shimano MT200 / SMRT10 S/M
Cockpit
Stem
CTM LCS 50/31.8 mm
Handlebar
CTM rise bar, 720/31.8 mm
Headset
NECO H156
Seat
Saddle
CTM
Seatpost
CTM SP3D1, 350/31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.467 mm | 1.398 mm | 1.332 mm |
| Front Center | 689 mm | 713 mm | 740 mm | 767 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 608 mm | 616 mm | 622 mm | 626 mm |
| Reach | 400 mm | 420 mm | 445 mm | 470 mm |
| Top Tube Length | 578 mm | 601 mm | 628 mm | 654 mm |
| Seat Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Seat Tube Length | 400 mm | 430 mm | 475 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1110 mm | 1134 mm | 1161 mm | 1188 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
