CUBE AIM, ONE ALLROAD 2025
2025 Urban
Estimate price |
790$
Weight | 16.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Flat Mount Brake, SIC Mount, FM Kickstand Mount
Suspension Fork
SR Suntour XCE, 100mm
Drivetrain
Rear Derailleur
Shimano RD-TX800, 8-Speed
Front Derailleur
Shimano FD-M315, Top Swing, 31.8mm Clamp
Shift Levers
Shimano SL-M315, Rapidfire-Plus
Cassette
Shimano CS-HG200, 12-32T
Crank
Shimano FC-M315, 36x22T, 170mm
Bottom Bracket
Thun Paso-ML, 73mm BSA
Chain
KMC Z8.3
Pedals
CUBE PP MTB
Wheels
Front Hub
Shimano DH-3D32, Hub Dynamo, QR
Rear Hub
CUBE Alloy Light, QR, 6-Bolt
Rims
CUBE EX25, 32H, Disc
Tires
CUBE MTB, 2.25
Brakes
Brakes
Clarks Clout 1, Hydr. Disc Brake PM/PM (160/160)
Cockpit
Stem
CUBE Performance Stem, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm
Grips
ACID React
Headset
CUBE FPH863, Semi-Integrated
Seat
Saddle
ACID Venec Lite
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.549 mm | 1.503 mm | 1.533 mm | 1.495 mm | 1.488 mm |
| Front Center | 632 mm | 660 mm | 684 mm | 705 mm | 722 mm |
| Rake | 30 mm | 42 mm | 47 mm | 47 mm | 42 mm |
| Trail | 98 mm | 85 mm | 87 mm | 87 mm | 92 mm |
| Stack | 595 mm | 598 mm | 627 mm | 637 mm | 656 mm |
| Reach | 384 mm | 398 mm | 409 mm | 426 mm | 441 mm |
| Top Tube Length | 555 mm | 575 mm | 595 mm | 615 mm | 635 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 340 mm | 370 mm | 420 mm | 470 mm | 515 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 107 mm | 110 mm | 110 mm | 121 mm | 141 mm |
| Chainstay Length | 441 mm | 441 mm | 461 mm | 461 mm | 461 mm |
| Wheelbase | 1068 mm | 1096 mm | 1137 mm | 1158 mm | 1175 mm |
| Bottom Bracket Drop | 52 mm | 52 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
