Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Urban Double Butted
Suspension Fork
Aluminium Rigid Fork
Drivetrain
Shift Levers
Shimano Alfine SL-S700
Crank
Gates CDX Center Track, 46T, BB Gates
Chain
Gates CDX Center Track, 111
Pedals
VP 615M
Wheels
Front Hub
Shimano Deore HB-M615, Centerlock
Rear Hub
Shimano Alfine SG-S700, 11-Speed
Rims
CUBE UX24, 32H, Disc
Tires
Schwalbe Marathon Supreme, Kevler, 42x622
Brakes
Brakes
Shimano Deore BR-M615, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Natural Fit Tour
Headset
FSA Orbit Z semi-integrated 1 1/8"
Seat
Saddle
Selle Royal Prestige
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.37 mm | 1.39 mm | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 631 mm | 632 mm | 639 mm | 649 mm | 660 mm |
| Rake | 52 mm | 53 mm | 54 mm | 53 mm | 53 mm |
| Trail | 67 mm | 60 mm | 52 mm | 53 mm | 53 mm |
| Stack | 540 mm | 557 mm | 580 mm | 599 mm | 618 mm |
| Reach | 403 mm | 407 mm | 416 mm | 421 mm | 426 mm |
| Top Tube Length | 566 mm | 576 mm | 592 mm | 602 mm | 613 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1057 mm | 1058 mm | 1065 mm | 1075 mm | 1086 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
EDITOR completes the Cube Editor model. 7 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Touring bikes average weight
Touring bikes weigh an average of 13.35 kg (29.43 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
EDITOR weighs 11.65 kg (25.68 lbs) and is considerably lighter than the average. To sum up, it’s 14.59% lighter than the average weight of Touring bikes.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the EDITOR model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. CUBE EDITOR is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
