Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Urban Double Butted
Suspension Fork
Aluminium Rigid Fork
Drivetrain
Shift Levers
Shimano Alfine SL-S700
Cassette
Gates CDX Center Track, 22T
Crank
Gates CDX Center Track, 46T, BB Gates
Chain
Gates CDX Center Track, 111
Pedals
VP 615M
Wheels
Front Hub
Shimano Deore HB-M6000, QR, Centerlock
Rear Hub
Shimano Alfine SG-S7001, 11-Speed, Nut, Centerlock
Rims
CUBE UX24, 32H, Disc
Tires
Schwalbe Marathon Supreme, Kevlar, 42x622
Brakes
Brakes
Shimano Deore BR-M6000, Hydr. Disc Brake (160/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Flat Race Bar, 660mm
Grips
CUBE Natural Fit Tour
Headset
FSA Orbit Z semi-integrated 1 1/8"
Seat
Saddle
Selle Royal Prestige
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.37 mm | 1.39 mm | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 631 mm | 632 mm | 639 mm | 649 mm | 660 mm |
| Rake | 52 mm | 53 mm | 54 mm | 53 mm | 53 mm |
| Trail | 67 mm | 60 mm | 52 mm | 53 mm | 53 mm |
| Stack | 540 mm | 557 mm | 580 mm | 599 mm | 618 mm |
| Reach | 403 mm | 407 mm | 416 mm | 421 mm | 426 mm |
| Top Tube Length | 566 mm | 576 mm | 592 mm | 602 mm | 613 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 115 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1057 mm | 1058 mm | 1065 mm | 1075 mm | 1086 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
EDITOR completes the Cube Editor model. CUBE launched 7 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Touring bikes average weight
Touring bikes weigh an average of 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
EDITOR weighs 11.6 kg (25.57 lbs) and is much lighter than the average. In short, the average Touring bike weight is 15.09% higher than this one.
EDITOR components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The EDITOR 2018 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The EDITOR comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
