CUBE HYDE ONE FE 2025
2025 Urban
Estimate price |
1,046$
Weight | 14.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Shimano -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite, Urban 29, Taper, Double Butted
Suspension Fork
CUBE TK Disc, C:62® Full Carbon, Taper, Flat Mount, 12x100mm
Drivetrain
Rear Derailleur
Shimano Essa RD-U2000-GS, 8-Speed
Shift Levers
Shimano SL-M315, Rapidfire-Plus
Crank
Shimano Essa FC-U2000-1, 40T
Bottom Bracket
Thun Paso-ML, 68mm, BSA
Chain
KMC Z8
Pedals
CUBE PP MTB
Wheels
Front Hub
Shutter Precision PL-7, Hub Dynamo, 12x100, Centerlock
Rear Hub
Shimano FH-QC300-HM, QR, Centerlock
Rims
CUBE EX25, 28H / 32H, Disc, Tubeless Ready
Tires
Schwalbe Big Apple, ActiveL, 55-622
Brakes
Brakes
Shimano BR-MT200, Hydr. Disc Brake (160/180)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Comfort Trail Bar, 700mm
Grips
ACID Travel
Headset
VP Semi-Integrated, Top 1/18", Bottom 1 1/2", Sealed Bearing
Seat
Saddle
Natural Fit Sequence
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm | 58cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.513 mm | 1.563 mm | 1.58 mm | 1.655 mm |
| Front Center | 643 mm | 643 mm | 642 mm | 652 mm | 663 mm |
| Rake | 50 mm | 61 mm | 50 mm | 52 mm | 52 mm |
| Trail | 80 mm | 56 mm | 67 mm | 65 mm | 65 mm |
| Stack | 573 mm | 596 mm | 619 mm | 632 mm | 662 mm |
| Reach | 392 mm | 394 mm | 396 mm | 400 mm | 400 mm |
| Top Tube Length | 551 mm | 565 mm | 580 mm | 595 mm | 605 mm |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm |
| Head Tube Angle | 69 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1104 mm | 1104 mm | 1103 mm | 1113 mm | 1124 mm |
| Bottom Bracket Drop | 69 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
