Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Fork RockShox Paragon Gold RL -
Groupset XT -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite Trekking Comfort IC Double Butted
Suspension Fork
Rock Shox Paragon Gold, 63mm, OneLock
Drivetrain
Rear Derailleur
Shimano XT RD-T8000, 10-Speed
Front Derailleur
Shimano XT FD-T8000, Top Swing, 31.8mm
Shift Levers
Shimano XT SL-T8000
Cassette
Shimano CS-M771, 11-34T
Crank
Shimano XT FC-T8000, Hollowtech II, 48x36x26T, 175mm, Integrated BB, Chainguard
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-HG95
Pedals
Trekking Gummiert
Wheels
Front Hub
Shimano XT DH-T8000, Hub Dynamo, QR
Rear Hub
Shimano XT FH-M8000, QR, Centerlock
Rims
CUBE EX21, 32H, Disc, Tubeless Ready
Tires
Schwalbe Marathon Supreme, Kevlar, 42x622
Brakes
Brakes
Shimano XT BR-M8000, Hydr. Disc Brake (180/160)
Cockpit
Stem
CUBE Performance Stem Pro, 31.8mm
Handlebar
CUBE Rise Trail Bar, 680mm
Grips
CUBE Natural Fit Comfort
Headset
FSA Orbit Z semi-integrated 1 1/8"
Seat
Saddle
Selle Royal Freccia Video Gel
Seatpost
CUBE Performance Post, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 54cm |
|---|---|---|---|
| Stack Reach Ratio | 1.72 mm | 1.66 mm | 1.73 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm |
| Front Center | 620 mm | 629 mm | 645 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 74 mm | 71 mm | 71 mm |
| Stack | 623 mm | 626 mm | 659 mm |
| Reach | 362 mm | 376 mm | 381 mm |
| Top Tube Length | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 150 mm | 150 mm | 185 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1050 mm | 1059 mm | 1075 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
About this model
KATHMANDU completes the Cube Kathmandu model. CUBE released 33 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Touring bikes average weight
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
KATHMANDU weighs 14.6 kg (32.19 lbs) and is a bit heavier than the average. To sum up, it’s 9.36% heavier than the average weight of Touring bikes.
Overview of components
Fork
The KATHMANDU comes factory-installed with the RockShox Paragon Gold RL fork. This has a travel range of mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on KATHMANDU are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
