Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Fork Manitou Mastodon Comp
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch PowerPack 500 -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Superlite, Gravity Casting, ARG, Double Butted, Disc Only, Tapered Headtube, Internal Cable Routing
Suspension Fork
Manitou Mastodon Comp, Tapered, 15x150mm, 120mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8000-DGS, ShadowPlus, 11-Speed
Shift Levers
Shimano XT SL-M8000, 11-Speed
Cassette
Shimano SLX CS-M7000, 11-46T
Crank
CUBE Fat Crank, 16T
Chain
KMC X11e Turbo
Wheels
Rims
Answer Fat Atac 80SL, 15x150mm / 12x177mm
Tires
Schwalbe Jumbo Jim Kevlar 4.0, Addix Speedgrip, Tubeless Easy
Brakes
Brakes
Magura MT5, Hydr. Disc Brake (180/180)
Cockpit
Stem
Race Face Ride 35
Handlebar
Race Face Ride 35, 760mm
Grips
CUBE Race Grip 31, 1-Clamp
Headset
FSA 1.5E ZS, Tapered, Top Zero-Stack 1 1/8" (OD 44mm), Bottom Zero-Stack 1 1/2" (OD 56mm)
Seat
Saddle
Selle Royal Voga
Seatpost
CUBE 120mm Adjustable Seatpost, Handlebar Lever, Internal Cable Routing, 30.9x420mm
Motor & Battery
Motor
Bosch Drive Unit Performance CX (75Nm) Cruise (250Watt)
Battery
Bosch PowerPack 500
Remote
Bosch Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.52 mm | 1.49 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm |
| Front Center | 671 mm | 693 mm | 713 mm |
| Rake | 50 mm | 51 mm | 51 mm |
| Trail | 78 mm | 77 mm | 77 mm |
| Stack | 630 mm | 639 mm | 648 mm |
| Reach | 402 mm | 420 mm | 436 mm |
| Top Tube Length | 593 mm | 614 mm | 633 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 450 mm | 495 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 112.5 mm | 122.5 mm | 132.5 mm |
| Chainstay Length | 489 mm | 489 mm | 489 mm |
| Wheelbase | 1154 mm | 1176 mm | 1196 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 26" | 26" | 26" |
About this model
NUTRAIL HYBRID 500 completes the Cube E Nutrail model. 4 e-bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Fatbike e-bikes
According to our math, the average price for a trustworthy Fatbike e-bike is 2033$. However, even though the average price of a Fatbike e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Fatbike e-bikes average weight
Fatbike e-bikes have an average weight of 31.21 kg (68.81 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
CUBE NUTRAIL HYBRID 500 it’s weighing 24.3 kg (53.57 lbs). At this weight, is much lighter than average. In other words, this model is 28.44% lighter than the average Fatbike e-bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
CUBE NUTRAIL HYBRID 500 2018 e-bike is equipped with the Manitou Mastodon Comp fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the NUTRAIL HYBRID 500 e-bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The NUTRAIL HYBRID 500 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
