CUBE REACTION TM 2024
2024 Mountain
Estimate price |
1,628$
Weight | 14.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Fork RockShox 35 Silver
-
Groupset X1, NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Lite, Trail Motion Geometry, AMF, ARG, Internal Cable Routing, Easy Mount Kickstand Ready, Tapered Headtube, Press Fit BB, Fits up to 2.8" 27.5+ Tires
Suspension Fork
RockShox 35 Silver TK Air, 15x110mm, Tapered, 130mm
Drivetrain
Rear Derailleur
SRAM NX Eagle™, 12-Speed
Shift Levers
SRAM SX Eagle™ Trigger
Cassette
SRAM PG-1210 Eagle™, 11-50T
Crank
SRAM X1 1000 Eagle™ DUB 30T, Boost
Bottom Bracket
SRAM DUB MTB, 92mm Pressfit
Chain
SRAM SX Eagle™
Pedals
ACID PP MTB
Wheels
Front Hub
Shimano HB-MT400-B, 15mm, Boost, Centerlock
Rear Hub
Shimano FH-MT400-B, 12mm, Boost, Centerlock
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Tires
Front: Maxxis Minion DHF, MaxxTerra/EXO+, Tubeless Ready, 2.5 WT, Rear: Maxxis Minion DHR II, MaxxTerra/EXO+, Tubeless Ready, 2.4 WT
Brakes
Brakes
Magura MT Thirty, Hydr. Disc Brake (203/180)
Cockpit
Stem
Newmen Evolution 318.4, 31.8mm
Handlebar
Newmen Evolution 318.20, 760mm
Grips
ACID React Pro
Headset
VP Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
Natural Fit Venec Lite
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 30,9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.575 mm | 1.511 mm | 1.467 mm | 1.435 mm |
| Bottom Bracket Height | 313 mm | 313 mm | mm | 313 mm |
| Front Center | 695 mm | 716 mm | 741 mm | 768 mm |
| Rake | 55 mm | 54 mm | 54 mm | 54 mm |
| Trail | 99 mm | 100 mm | mm | 100 mm |
| Stack | 622 mm | 627 mm | 638 mm | 653 mm |
| Reach | 395 mm | 415 mm | 435 mm | 455 mm |
| Top Tube Length | 576 mm | 598 mm | 621 mm | 646 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 405 mm | 450 mm | 490 mm | 540 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 102 mm | 107 mm | 119 mm | 135 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1115 mm | 1136 mm | 1161 mm | 1188 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm |
| Wheels | 29" | 29" | 20" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
