CUBE REACTION TM ONE 2025
2025 Mountain
Estimate price |
1,279$
Weight | 15.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Suntour XCR Air
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium Lite, Trail Motion Geometry, AMF, Internal Cable Routing, Tapered Headtube, ISCG05, Boost 148, UDH™
Suspension Fork
SR Suntour XCR34 2CR Air, Tapered, 15x110mm, 140mm
Drivetrain
Rear Derailleur
Shimano Cues RD-U6000-GS, 10-Speed
Shift Levers
Shimano Cues SL-U6000, Rapidfire-Plus
Cassette
Shimano Cues CS-LG400, 11-48T
Crank
Shimano Cues FC-U6000-1, 32T
Bottom Bracket
Prowheel BSA PW-MB68
Chain
KMC xGlide
Wheels
Front Hub
CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
Rear Hub
CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Tires
Front: Schwalbe Magic Mary, Performance, 2.4, Rear: Schwalbe Big Betty, Performance, 2.4
Brakes
Brakes
Magura MT Thirty, Hydr. Disc Brake (180/203)
Cockpit
Stem
CUBE Performance CPS-Race
Handlebar
CUBE Rise Trail Bar, 760mm
Grips
ACID React Pro
Headset
VP Integrated, Top 1 1/8", Bottom 1 1/2"
Seat
Saddle
ACID Venec Lite
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.498 mm | 1.427 mm | 1.437 mm | 1.374 mm | 1.336 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 707 mm | 727 mm | 761 mm | 781 mm | 805 mm |
| Rake | 37 mm | 37 mm | 44 mm | 44 mm | 44 mm |
| Trail | 125 mm | 125 mm | 117 mm | 117 mm | 117 mm |
| Stack | 605 mm | 605 mm | 635 mm | 635 mm | 644 mm |
| Reach | 404 mm | 424 mm | 442 mm | 462 mm | 482 mm |
| Top Tube Length | 570 mm | 590 mm | 610 mm | 630 mm | 653 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 320 mm | 370 mm | 405 mm | 420 mm | 470 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 408 mm | 408 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1111 mm | 1131 mm | 1181 mm | 1201 mm | 1226 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
