CUBE STEREO HYBRID ONE22, SLT 2025
2025 E-bike
Estimate price |
5,734$
Weight | 26.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Float 36
-
Groupset XT -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTube -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
Suspension Fork
Fox 36 Float GRIP, 3-Position w/Micro Adjust, Tapered, 15x110mm, E-Bike Optimized, 130mm
Rear Shock
Fox Float EVOL, 185x52,5mm, Open/Firm Mode, Trunnion Mount
Drivetrain
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shift Levers
Shimano XT SL-M8100-IR, Direct Attach
Cassette
Shimano XT CS-M8100, 10-51T
Crank
ACID MTB Hybrid Pro, 38T
Chain
KMC e12
Chain Guide
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Pedals
ACID PP MTB
Wheels
Rims
Newmen Performance 30, 28/32 Spokes (Base/Strong), 15x110mm / 12x148mm, Tubeless Ready
Tires
Schwalbe Johnny Watts 365, Performance, Kevlar, 2.6
Brakes
Brakes
Magura Gustav PRO, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Cockpit
Stem
CUBE Performance Stem E-MTB 35, FPI-Link
Handlebar
CUBE Rise Trail Bar 35
Grips
ACID Hybrid Perform
Headset
ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
Seat
Saddle
ACID Venec EMTB Plus 145
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Motor & Battery
Motor
Bosch Drive Unit Performance Line CX, Smart System
Battery
Bosch PowerTube
Remote
Bosch LED Remote
Charger
Bosch 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.457 mm | 1.393 mm | 1.351 mm |
| Bottom Bracket Height | 332 mm | 331 mm | 331 mm | 331 mm |
| Front Center | 732 mm | 755 mm | 786 mm | 818 mm |
| Rake | 43 mm | 43 mm | 43 mm | 44 mm |
| Trail | 108 mm | 116 mm | 116 mm | 115 mm |
| Stack | 638 mm | 647 mm | 656 mm | 670 mm |
| Reach | 417 mm | 444 mm | 471 mm | 496 mm |
| Top Tube Length | 570 mm | 600 mm | 630 mm | 660 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 405 mm | 420 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 163 mm | 132 mm | 142 mm | 157 mm |
| Chainstay Length | 455 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1186 mm | 1240 mm | 1271 mm | 1303 mm |
| Bottom Bracket Drop | 23 mm | 43 mm | 43 mm | 43 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
