CUBE STEREO HYBRID ONE22, SLX 800 ALLROAD 2025
2025 E-bike
Estimate price |
5,234$
Weight | 27.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Travel Rear 120mm -
Fork Fox AWL
-
Groupset XT, Deore -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Bosch PowerTube 800 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points, Integrated Seatclamp
Suspension Fork
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm
Rear Shock
Fox Float Rhythm RC, 185x52,5mm, Open/Firm Mode, Trunnion Mount
Drivetrain
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shift Levers
Shimano Deore SL-M6100-IR, Direct Attach, Rapidfire-Plus
Cassette
Shimano Deore CS-M6100, 10-51T
Crank
ACID MTB Hybrid Pro, 38T
Chain
KMC e12
Chain Guide
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Pedals
ACID PP MTB
Wheels
Front Hub
CUBE Engineered By Newmen, 15mm, Boost, Centerlock
Rear Hub
CUBE Engineered By Newmen, 12mm, Boost, Centerlock
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Tires
Schwalbe Smart Sam, Performance, 2.6
Brakes
Brakes
Shimano XT BR-M8120, Hydr. Disc Brake (203/203)
Cockpit
Stem
CUBE Performance Stem E-MTB 35, FPI-Link
Handlebar
CUBE Rise Trail Bar 35
Grips
ACID Hybrid Perform
Headset
ACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
Seat
Saddle
ACID Venec EMTB Plus 145
Seatpost
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Motor & Battery
Motor
Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System
Battery
Bosch PowerTube 800
Remote
Bosch Purion 200 w/ Integrated Display
Charger
Bosch 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.457 mm | 1.393 mm | 1.351 mm |
| Bottom Bracket Height | 332 mm | 312 mm | 312 mm | 331 mm |
| Front Center | 732 mm | 755 mm | 786 mm | 818 mm |
| Rake | 43 mm | 43 mm | 43 mm | 44 mm |
| Trail | 108 mm | 108 mm | 108 mm | 115 mm |
| Stack | 638 mm | 647 mm | 656 mm | 670 mm |
| Reach | 417 mm | 444 mm | 471 mm | 496 mm |
| Top Tube Length | 570 mm | 600 mm | 630 mm | 660 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 405 mm | 420 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 163 mm | 132 mm | 142 mm | 157 mm |
| Chainstay Length | 455 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1186 mm | 1240 mm | 1271 mm | 1303 mm |
| Bottom Bracket Drop | 23 mm | 43 mm | 43 mm | 43 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
