Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Torayca T1100 / T800 and XN60 Carbon
Suspension Fork
De Rosa Carbon 1 1/8" - 1 1/4"
Drivetrain
Bottom Bracket
BB86.5mm Required
Cockpit
Headset
Integrated 1 1/8" - 1 1/4" Required
Seat
Seatpost
31.6mm Required
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|---|
| Top Tube Length | 510.7 mm | 522 mm | 537.9 mm | 547.9 mm | 557.5 mm | 568 mm | 578 mm | 592.3 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.4 ° | 73.9 ° | 73.5 ° | 73 ° | 72.6 ° | 72.6 ° |
| Seat Tube Length | 471 mm | 501 mm | 521 mm | 541 mm | 551 mm | 571 mm | 591 mm | 611 mm |
| Head Tube Length | 110 mm | 117.2 mm | 126.2 mm | 134.7 mm | 144 mm | 156 mm | 170 mm | 190 mm |
| Chainstay Length | 405 mm | 405 mm | 407 mm | 408 mm | 410 mm | 412 mm | 414 mm | 414 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Protos Frameset is part of the Derosa Protos model. 8 frames variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race frames average price
According to our math, the average price for a trustworthy Race frame is 2445$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race frame. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
This frame was released in 2016 and its price was 4995$. Comparing this to the average Race frame price, we see that the price is 104.29% more expensive.
Overview of components
Fork material
When it comes to the fork, this frame has a carbon one, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
