Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 29" -
Travel Rear 165mm -
Suspension Full
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Carbon Construction
Drivetrain
Crank
Minimum Q-factor of 168mm
Bottom Bracket
73mm BSA Threaded
Cockpit
Headset
ZS44/28.6 upper and a ZS56/40 lower headset cup
Seat
Seatpost
Internal dropper routing with internal cable routing. 34.9”
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.348 mm | 1.286 mm | 1.231 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 794 mm | 829 mm | 864 mm |
| Rake | 44 mm | 44 mm | 45 mm |
| Trail | 131 mm | 131 mm | 130 mm |
| Stack | 620 mm | 630 mm | 640 mm |
| Reach | 460 mm | 490 mm | 520 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° |
| Head Tube Angle | 64.3 ° | 64.3 ° | 64.3 ° |
| Head Tube Length | 92 mm | 108 mm | 114 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1233 mm | 1268 mm | 1303 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
CLAYMORE Frame belongs to the Deviate Claymore model. Deviate launched 2 frames of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro frames average price
According to our math, the average price for a trustworthy Enduro frame is 1895$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Enduro frames average weight
Enduro frames have an average weight of 3.44 kg (7.58 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
CLAYMORE Frame weighs 3.2 kg (7.05 lbs) and is a bit lighter than the average. To sum up, it’s 7.5% lighter than the average weight of Enduro frames.
CLAYMORE Frame components
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Sizes
This frame is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
The Deviate model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
