Devinci E-Hatchet Tour Mahle X30 2025
2025 E-bike
Estimate price |
3,440$
Weight | 14.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor MAHLE 250W 45Nm hub-drive -
Battery Mahle iX2 | 36V | 237Wh -
Drivetrain 2 × 12 -
Brakes Shimano GRX 600 Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 171cm
MD
169cm - 180cm
LG
178cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum R03
Suspension Fork
Carbon OSC
Drivetrain
Rear Derailleur
Shimano GRX820 | 12s
Front Derailleur
Shimano GRX820 | 2s
Shift Levers
Shimano GRX610 | 12s
Cassette
Shimano 105 | 12s | 11-34T
Crank
Shimano GRX610 | 12s | 46/30T
Bottom Bracket
Mahle X30 TCS BB86 Torque Sensor
Chain
Shimano M6100 | 12s
Wheels
Front Hub
Formula Disc | Sealed bearings | TA 12x100mm
Rear Hub
Mahle X30 Drive Unit
Rims
Front: V2 Comp db | 24mm inner, Rear: V2 Comp db | 24mm inner
Spokes
Stainless 14G
Tires
WTB Vulpine | 700x40c
Brakes
Brakes
Shimano GRX610 | 2s
Cockpit
Stem
V2 Pro | B:31.8mm | 6°
Handlebar
V2 Pro | B:31.8mm | R:70mm | D:125mm | 16° FLARE
Headset
FSA No.55R | Internal Routing
Seat
Saddle
Devinci
Seatpost
Devinci | 27.2mm
Motor & Battery
Motor
Mahle X30 Drive Unit | 250W | 45Nm
Battery
Mahle iX2 | 36V | 237Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.438 mm | 1.492 mm | 1.556 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm |
| Front Center | 591 mm | 608 mm | 626 mm |
| Rake | 47 mm | 47 mm | 47 mm |
| Trail | 74 mm | 70 mm | 67 mm |
| Stack | 535 mm | 570 mm | 610 mm |
| Reach | 372 mm | 382 mm | 392 mm |
| Top Tube Length | 524 mm | 550 mm | 577 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 410 mm | 490 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 145 mm | 185 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1011 mm | 1029 mm | 1047 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm |
| Standover Height | 680 mm | 744 mm | 781 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 169 cm | 178 cm |
| Rider Max Height | 171 cm | 180 cm | 190 cm |
