Devinci Hatchet Tiagra 20S 2025
2025 Road
Estimate price |
1,593$
Weight | 11.11 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Shimano Mechanical Disc
Sizing
Recommended size guide.
XS
147cm - 160cm
SM
157cm - 171cm
MD
169cm - 180cm
LG
178cm - 187cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum R03
Suspension Fork
Devinci Full Carbon
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 | 10s
Front Derailleur
Shimano Tiagra 4700 | 2s
Shift Levers
Shimano Tiagra ST-4700 | 10s
Cassette
Shimano HG500 | 10s | 11-34T
Crank
FSA Vero | 50/34T
Chain
Shimano HG54
Wheels
Front Hub
Formula Disc | Sealed bearings | TA 12x100mm
Rear Hub
Formula Disc sealed bearings | TA 12x142mm
Rims
Front: V2 Comp db | 21mm inner, Rear: V2 Comp db | 21mm inner
Spokes
Stainless 14G
Tires
Maxxis Refuse | 700x32c
Brakes
Brakes
Shimano RS305 | Mechanic
Cockpit
Stem
V2 Pro | B:31.8mm | 6°
Handlebar
V2 Pro | B:31.8mm | R:70mm | D:120mm
Headset
FSA Orbit C40 | Integrated
Seat
Saddle
Devinci
Seatpost
Devinci | 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.404 mm | 1.46 mm | 1.497 mm | 1.544 mm | 1.579 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 599 mm | 612 mm | 623 mm | 640 mm | 649 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 76 mm | 73 mm | 69 mm | 69 mm | 66 mm |
| Stack | 528 mm | 559 mm | 584 mm | 613 mm | 638 mm |
| Reach | 376 mm | 383 mm | 390 mm | 397 mm | 404 mm |
| Top Tube Length | 527 mm | 543 mm | 562 mm | 583 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 530 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 140 mm | 165 mm | 195 mm | 220 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1020 mm | 1033 mm | 1044 mm | 1061 mm | 1071 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 676 mm | 707 mm | 740 mm | 774 mm | 809 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 169 cm | 178 cm | 185 cm |
| Rider Max Height | 160 cm | 171 cm | 180 cm | 187 cm | 193 cm |
