Devinci Hatchet Vista Cues 10s 2025
2025 Road
Estimate price |
1,799$
Weight | 10.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 160cm
SM
157cm - 171cm
MD
169cm - 180cm
LG
178cm - 187cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum R03
Suspension Fork
Carbon OSC
Drivetrain
Rear Derailleur
Shimano Cues RD-U6000 | 10s
Shift Levers
Shimano Cues ST-U6030 | 10s
Cassette
Shimano LG400-10 | 11-48T | 10s
Crank
Shimano Cues FC-U6030 | 40T
Bottom Bracket
FSA BB-6002 | T47
Chain
Shimano LG500 | 10s
Wheels
Front Hub
Formula RX-512 Disc | Sealed bearings | TA 12x100mm
Rear Hub
Formula RX-142 Disc | Sealed bearings | TA 12x142mm
Rims
Front: V2 Comp DB | 24mm inner, Rear: V2 Comp DB | 24mm inner
Spokes
Stainless 14G
Tires
WTB Resolute | 700x42c | Tan Sidewall
Brakes
Brakes
Front: Shimano Cues BL-U6030 | Hydraulic | Flat Mount, Rear: Shimano Cues BL-U6030 | Hydraulic | Flat Mount
Cockpit
Stem
V2 Pro | B:31.8mm | 6°
Handlebar
V2 Pro | B:31.8mm | R:70mm | D:125mm | 16° FLARE
Headset
FSA no.55R | Internal Routing
Seat
Saddle
Devinci
Seatpost
Devinci | 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.46 mm | 1.492 mm | 1.537 mm | 1.569 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 595 mm | 612 mm | 628 mm | 644 mm | 658 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 47 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm | 74 mm |
| Stack | 530 mm | 559 mm | 582 mm | 610 mm | 634 mm |
| Reach | 376 mm | 383 mm | 390 mm | 397 mm | 404 mm |
| Top Tube Length | 532 mm | 548 mm | 562 mm | 577 mm | 598 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 530 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 140 mm | 165 mm | 195 mm | 220 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1014 mm | 1031 mm | 1047 mm | 1063 mm | 1078 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 675 mm | 710 mm | 751 mm | 786 mm | 821 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 169 cm | 178 cm | 185 cm |
| Rider Max Height | 160 cm | 171 cm | 180 cm | 187 cm | 193 cm |
