Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 160cm
SM
157cm - 170cm
MD
168cm - 180cm
LG
178cm - 187cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum G02
Suspension Fork
SR Suntour XCR Air LO-R-DS | w/Lock-out |100mm
Drivetrain
Rear Derailleur
Shimano Deore M5120 | 10s
Shift Levers
Shimano Deore M4100 | 10s
Cassette
Sunrace | 10s | 11-46T
Crank
Alloy 2pcs | 28T Narrow Wide
Chain
Shimano HG54 | 10s
Chain Guide
CD-04D
Pedals
Wellgo M095
Wheels
Front Hub
Formula Disc | QR 9x100mm
Rear Hub
Formula Disc | QR 10x135mm
Rims
V2 Comp db | 24mm inner
Spokes
Stainless 14G
Tires
Kenda Amrak | 29x2.40
Brakes
Brakes
Shimano MT200 | Hydraulic
Disk Rotors
Shimano SM-RT26 | 160mm
Cockpit
Stem
V2 Comp | B:31.8mm | 0°
Handlebar
V2 Comp | B:31.8mm | R:15mm | W:720mm
Grips
Kraton
Headset
CH-6201-1 | Zero Stack
Seat
Saddle
Devinci
Seatpost
Devinci | 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.58 mm | 1.56 mm | 1.54 mm | 1.53 mm |
| Bottom Bracket Height | 317.5 mm | 317.5 mm | 317.5 mm | 317.5 mm | 317.5 mm |
| Stack | 608 mm | 608 mm | 618 mm | 627 mm | 646 mm |
| Reach | 375 mm | 385 mm | 396 mm | 407 mm | 421 mm |
| Top Tube Length | 562 mm | 572 mm | 592 mm | 612 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 72.5 ° | 72 ° | 72 ° |
| Seat Tube Length | 380 mm | 400 mm | 450 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1079 mm | 1089 mm | 1104 mm | 1118 mm | 1139 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Standover Height | 687 mm | 701 mm | 737 mm | 755 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 147 cm | 157 cm | 168 cm | 178 cm | 185 cm |
| Rider Max Height | 160 cm | 170 cm | 180 cm | 187 cm | 193 cm |
Model Overview
Riff Deore 10S belongs to the Devinci Riff model. There are 5 bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1012$. Doing a quick comparison, we notice that Riff Deore 10S price is 88.24% smaller than the average cost of a Crosscountry bike.
Riff Deore 10S components
Fork
The Riff Deore 10S comes factory-installed with the Suntour XCR Air fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Riff Deore 10S model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Devinci Riff Deore 10S has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 147 cm – 193 cm (4.82 ft – 6.33 ft). In conclusion, you won’t have a problem finding one that suits you.
