Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Altus -
Motor hub-drive -
Battery 250 Wh, in Unterrohr integriert -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
SM
158cm - 170cm
MD
168cm - 179cm
MD
168cm - 179cm
LG
176cm - 187cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Leichter aluminiumrahmen mit innenverlegten zügen und flaschenhalterösen
Drivetrain
Rear Derailleur
Shimano Altus M2000, langer Käfig
Shift Levers
Shimano Altus M2010, 9fach
Cassette
Shimano HG200, 11-36 Z., 9-fach
Crank
ProWheel Pro, Aluminium, Narrow-Wide-Stahlkettenblatt (42 Z.), 175 mm Kurbelarmlänge Drehmomentsensor, mit Gewinde, 122,5 mm Achslänge
Chain
KMC E9S, 9fach
Pedals
rutschfeste Pedale mit Reflektoren
Wheels
Rims
Bontrager Connection, Hohlkammerfelge, 32-Loch, 20 mm Innenweite, Presta-Ventil Formula DC-20, Aluminium, 6-Loch-Scheibenaufnahme, 5 x 100 mm-Schnellspannachse Hyena Nabenmotor, 40 Nm, 250 W
Tires
Bontrager H2 Comp, Reflektorstreifen, Drahtwulstkern, 30 TPI, 700 x 40 mm
Brakes
Brakes
Front: Hydraulische Scheibenbremse von Shimano, MT200 Bremshebel, UR300 Bremssattel // Hydraulische Scheibenbremse von Shimano, MT200 Bremshebel, UR300 Bremssattel Shimano RT26, 6-Loch-Scheibenaufnahme, 160 mm
Cockpit
Stem
Bontrager Comp, 31 8 mm, Blendr-kompatibel, 7 Grad, 90 mm Länge
Handlebar
Aluminium-Lowriser, 31,8 mm, 25 mm Rise, 11 Grad Krümmung, 660 mm Breite
Seat
Saddle
Selle Royal Vivo Moderate Ergo mit Royalgel
Seatpost
Bontrager aus Aluminium, 31,6 mm, 12 mm Versatz, 400 mm Länge
Motor & Battery
Motor
Tretlager
Battery
250 Wh, in Unterrohr integriert
Charger
2 A, 42 V Ausgangsleistung, 100 V – 240 V AC Eingangsleis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | LG | LG |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.581 mm | 1.581 mm | 1.61 mm | 1.61 mm | 1.654 mm | 1.654 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 633 mm | 633 mm | 636 mm | 636 mm | 650 | 650 |
| Rake | 50 mm | 50 mm | 49 mm | 49 mm | 51 mm | 51 mm |
| Trail | 76 mm | 76 mm | 73 mm | 73 mm | 69 mm | 69 mm |
| Stack | 604 mm | 604 mm | 620 mm | 620 mm | 650 | 650 |
| Reach | 382 mm | 382 mm | 385 mm | 385 mm | 393 mm | 393 mm |
| Top Tube Length | 569 mm | 569 mm | 574 mm | 574 mm | 592 mm | 592 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 408 mm | 408 mm | 463 mm | 463 mm | 507 mm | 507 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 155 mm | 155 mm | 170 mm | 170 mm | 200 mm | 200 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1092 mm | 1092 mm | 1095 mm | 1095 mm | 1109 mm | 1109 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 655 mm | 655 mm | 672 mm | 672 mm | 693 mm | 693 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 168 cm | 176 cm | 176 cm |
| Rider Max Height | 170 cm | 170 cm | 179 cm | 179 cm | 187 cm | 187 cm |
