Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
SM
158cm - 170cm
MD
168cm - 179cm
MD
168cm - 179cm
LG
176cm - 187cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminium, Lowstep, Gepäckträger- und Schutzblechösen, DuoTrap S-kompatibel, IS-Scheibenbremsaufnahme, 135 x 5 mm-Schnellspannachse
Suspension Fork
SR Suntour NEX, Spiralfeder, verstellbare Federvorspannung, 50 mm Federweg, 100 x 5 mm Schnellspannachse
Drivetrain
Rear Derailleur
Shimano Altus M2000, langer Käfig
Front Derailleur
Shimano Tourney TY710, 34,9 mm Klemmdurchmesser, Top Swing, Dual Pull
Shift Levers
Shimano Altus M315, 3fach // Shimano M315, 8-fach
Cassette
Shimano, 8fach, 12-32 Z.
Crank
Shimano, 48/38/24 Z. VP BC73C, 68 mm, Gewindepatronenlager, 122,5 mm Achslänge
Chain
KMC Z8
Pedals
rutschfeste Pedale mit Reflektoren
Wheels
Rims
Bontrager Connection, Hohlkammerfelge, 32-Loch, 20 mm Innenweite, Presta-Ventil // Bontrager Connection, Hohlkammerfelge, 32-Loch, 20 mm Innenweite, Presta-Ventil Shimano Nabendynamo 3,0 Watt Shimano TX505, Center Lock-Scheibenaufnahme
Brakes
Brakes
Front: Hydraulische Scheibenbremse Shimano MT200 // Hydraulische Scheibenbremse Shimano MT200 Shimano RT10, Center Lock-Scheibenaufnahme, 160 mm
Cockpit
Stem
Aluminium, verstellbar, 25,4 mm, Länge 85 mm
Handlebar
Aluminium, 25,4-mm-Klemmung, 20 mm Rise, 630 mm Breite
Headset
Semi-integrierter Gewindesteuersatz, Semi-Kompaktlager, 1 1/8"
Seat
Saddle
Selle Royal Nuvola
Seatpost
Aluminium, verstellbare Federvorspannung, 27,2 mm, 300 mm Länge
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | LG | LG |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.668 mm | 1.668 mm | 1.673 mm | 1.673 mm | 1.666 mm | 1.666 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm | 302 mm |
| Front Center | 633 mm | 633 mm | 642 mm | 642 mm | 647 mm | 647 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 40 mm | 40 mm |
| Trail | 81 mm | 81 mm | 81 mm | 81 mm | 81 mm | 81 mm |
| Stack | 634 mm | 634 mm | 644 mm | 644 mm | 653 mm | 653 mm |
| Reach | 380 mm | 380 mm | 385 mm | 385 mm | 392 mm | 392 mm |
| Top Tube Length | 568 mm | 568 mm | 594 mm | 594 mm | 604 mm | 604 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 440 mm | 440 mm | 500 mm | 500 mm | 550 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 160 mm | 160 mm | 170 mm | 170 mm | 180 mm | 180 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 1096 mm | 1096 mm | 1105 mm | 1105 mm | 1110 mm | 1110 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 654 mm | 654 mm | 682 mm | 682 mm | 694 mm | 694 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 168 cm | 176 cm | 176 cm |
| Rider Max Height | 170 cm | 170 cm | 179 cm | 179 cm | 187 cm | 187 cm |
