Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Womens Alternative Road, Endurance Geometry, Relaxed head angle, Fully Butted 6061-T6 Alloy Disc Specific frame, Formed Top tube w/ Integrated Tapered Headtube
Suspension Fork
DB Gravel Disc, Alloy 1.5" Taper Disc Fork
Drivetrain
Rear Derailleur
Shimano Sora RD-3500
Front Derailleur
Shimano Sora FD-3500, 31.8
Shift Levers
Shimano Sora SL-3500 Flat Bar 9spd
Cassette
Shimano HG-50 Tiagra 9spd (11-32t)
Crank
FSA Gossamer Cross Mega Exo, 46/36T
Bottom Bracket
FSA Mega Exo
Chain
KMC Z99
Pedals
Wellgo Alloy Road
Wheels
Front Hub
Alloy 28h Disc
Rear Hub
Alloy 28h Disc, Cassette
Rims
DB Equation CX 28h, 23mm wide
Spokes
14g Stainless Steel
Tires
Kenda Warthog 700x40
Brakes
Brakes
Avid BB5 Mechanical Disc, 160mm/140mm G2 Rotors
Brake Levers
Avid FR5
Cockpit
Stem
DB X-Durance 3D Forged, +/-7° Rise 31.8
Handlebar
DB Flat Bar, 680mm wide,31.8mm
Grips
Diamondback Dual Density Grip
Headset
FSA No.42B Sealed 1-1/8"/1.5" ACB Integrated
Seat
Saddle
DB Performance Womens Road
Seatpost
DB X-Durance, Alloy 27.2mmx350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.53 mm | 1.55 mm |
| Front Center | 577 mm | 573 mm | 589 mm | 599 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 105 mm | 93 mm | 75 mm | 66 mm |
| Stack | 534 mm | 547 mm | 563 mm | 579 mm |
| Reach | 373 mm | 369 mm | 369 mm | 374 mm |
| Top Tube Length | 493 mm | 503 mm | 528 mm | 548 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 989 mm | 985 mm | 1001 mm | 1011 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 700 | 724 mm | 749 mm | 774 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Haanjenn belongs to the Diamondback Haanjenn model. Diamondback launched 12 bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter bikes average price
Our math shows that the average cost of a dependable Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 499$. Comparing this to the average Commuter bike price, we see that the price is 52.71% lower.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The Haanjenn 2016 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Haanjenn has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Diamondback Haanjenn bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
