Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
Suspension Fork
SR Suntour XCE-28 100mm of Travel with Pre-Load Adjuster, IS Disc mounts
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney TY300
Front Derailleur
Shimano Tourney TY500, Dual Pull
Shift Levers
Shimano SL-M315 3x7 Speed, Rapid Fire Shifter
Cassette
Shimano MFTZ500 14-28 Tooth Freewheel
Crank
Shimano Tourney TY301, 42/34/24t
Bottom Bracket
BSA, Sealed Cartridge Bearing
Chain
KMX Z-7
Pedals
Wellgo Plastic Body Platform
Wheels
Front Hub
Formula DC-19 Aluminum 6 bolt Disc, Quick Release
Rear Hub
Formula DC-31, Aluminum 6 bolt Disc, Quick Release
Rims
Aluminum MTB DDM-2 Double Wall, 32 hole
Spokes
Steel J-Bend
Tires
Vee Tire Rail Escape, 27.5x2.25" or 29x2.25"
Brakes
Brakes
Radius BH860 Hydraulic Levers with Micro Adjust
Brake Levers
Radius BH860 Hydraulic Levers with Micro Adjust
Cockpit
Stem
Aluminum MTB 31.8 Bar Bore Stem
Handlebar
Aluminum 31.8mm Bar, 25mm Rise
Grips
MTB Grip
Headset
1-1/8 Semi Integrated,Cartridge Bearing
Seat
Saddle
MTB Saddle
Seatpost
Aluminum 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.403 mm | 1.354 mm | 1.307 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 689 mm | 714 mm | 740 mm | 766 mm |
| Rake | 47 mm | 47 mm | 48 mm | 47 mm |
| Trail | 95 mm | 95 mm | 94 mm | 95 mm |
| Stack | 599 mm | 599 mm | 608 mm | 617 mm |
| Reach | 402 mm | 427 mm | 449 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | 660 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1134 mm | 1159 mm | 1185 mm | 1211 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 775 mm | 784 mm | 791 mm | 804 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 169 cm | 176 cm | 187 cm |
| Rider Max Height | 172 cm | 179 cm | 189 cm | 198 cm |
