Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 75mm -
Fork SunTour
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB 6061-T6 heat-treated 27.5" / butted aluminum w/ gusset, replaceable hanger
Suspension Fork
SR Suntour M3030 27.5", Coil Spring, 75mm Travel, Alloy Crown and Lowers
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF-51 7spd
Cassette
Shimano 7spd Freewheel (14-28t)
Crank
MTB Steel Arm w/chainguard 24/32/42t
Bottom Bracket
Square Taper - 5pc
Chain
KMC-Z51
Pedals
MTB Resin
Wheels
Front Hub
32h Alloy QR
Rear Hub
32h Alloy QR
Rims
32h Diamondback XC260 27.5" Doublewall
Spokes
14g Stainless Steel
Tires
Chaoyang Hornet 27.5x2.1
Brakes
Brakes
Tektro Alloy Linear
Brake Levers
Shimano EF-51
Cockpit
Stem
Alloy 4 bolt Ahead
Handlebar
Steel Riser
Grips
DB Kraton
Headset
Ahead 1 1/8"
Seat
Saddle
DB Men's ATB
Seatpost
27.2mm Suspension Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Bottom Bracket Height | 308 mm | 308 mm |
| Rake | 38 mm | 38 mm |
| Top Tube Length | 557 mm | 572 mm |
| Seat Tube Angle | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm |
| Chainstay Length | 428 mm | 428 mm |
| Wheelbase | 1030 mm | 1047 mm |
| Bottom Bracket Drop | 47 mm | 47 mm |
| Standover Height | 633 mm | 676 mm |
| Wheels | 27" | 27" |
Model Overview
Laurito completes the Diamondback Laurito model. Diamondback launched 1 bike of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
The Laurito comes factory-installed with the SunTour fork. This has a travel range of 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When leaving the production line, the Laurito model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Laurito has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
