Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 80mm -
Fork SunTour XCT
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lux 27.5 W! Women's Specific Butted 6061-T6 Aluminum Frame, Super Low TT for Increased Clearance, w/ Formed Top / Down Tube w/ Replaceable Hanger, Disc Only
Suspension Fork
SR Suntour XCT, 80mm Travel, Coil Spring, 28.6mm Stanchions
Drivetrain
Rear Derailleur
Shimano Acera M360, 8 Speed
Front Derailleur
Shimano TX50, Top Swing, Dual Pull, 34.9mm Band Clamp
Shift Levers
Shimano Altus EF-51 Easyfire, 3x8 Speed
Cassette
Shimano HG-31, 8 Speed, Cassette, 11-32T
Crank
SR Suntour XCT, 42/32/22T
Bottom Bracket
Square Taper - 5pc
Chain
KMC Z82
Pedals
Alloy Forged
Wheels
Front Hub
32h SL-7 Alloy w/ CNC Disc Mount
Rear Hub
32h SL-7 Alloy w/ CNC Disc Mount, Cassette
Rims
DB SL-7 27.5" 32h Doublewall
Spokes
14g Stainless
Tires
Chaoyang Hornet 27.5x2.1
Brakes
Brakes
Tektro Aires Mechanical Disc w/ 180mm Front / 160mm Rear Rotors
Brake Levers
Shimano Altus EF-51
Cockpit
Stem
DB 3D Forged, +/- 7° Rise, 31.8mm Bar Bore
Handlebar
DB Laser Series, Low Rise, 600mm Wide, 31.8mm Bar Bore
Grips
Devine Women's Specific D2 Kraton
Headset
FSA IS-3 Integrated
Seat
Saddle
Devine Edition MTB saddle
Seatpost
DB Laser Micro Adjust 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Rake | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 549 mm | 572 mm | 587 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1044 mm | 1069 mm | 1084 mm |
| Standover Height | 646 mm | 646 mm | 658 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Lux ST is part of the Diamondback Lux model. Diamondback released 26 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Diamondback released this model in 2016, its price was 499$. Comparing this to the average Crosscountry bike price, we see that the price is 281.76% smaller.
Lux ST components
Fork
The Lux ST comes factory-installed with the SunTour XCT fork. This has a travel range of 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Lux ST model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Diamondback Lux ST bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
