Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 27.5" -
Travel Front 75mm -
Fork SunTour
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Durable Steel 27.5" MTB Frame w/ Fender / Rack Mounts
Suspension Fork
SR Suntour M3030 27.5", Coil Spring, 75mm Travel, Alloy Crown and Lowers
Drivetrain
Rear Derailleur
Shimano Altus 7spd
Front Derailleur
Shimano Tourney, top pull, 31.8
Shift Levers
Shimano Altus EF-51 7spd
Cassette
Shimano TZ21 7 Speed Freewheel 14-28
Crank
MTB w/ chainguard 24/32/42t
Bottom Bracket
Square Taper - 5pc
Chain
KMC-Z51
Pedals
MTB Resin
Wheels
Front Hub
36h Alloy QR
Rear Hub
32h Alloy QR
Rims
36h R-1000 Alloy 27.5"
Spokes
14g
Tires
Chaoyang Hornet 27.5x2.1
Brakes
Brakes
Alloy Linear
Brake Levers
Alloy Linear
Cockpit
Stem
Steel Aheadw/ Alloy Cap
Handlebar
Steel Riser
Grips
MTB Kraton
Headset
Ahead 1 1/8"
Seat
Saddle
DB Men's ATB
Seatpost
Steel Pillar 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm | 308 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Top Tube Length | 528 mm | 540 mm | 561 mm | 571 mm | 584 mm | 596 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 305 mm | 356 mm | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1015 mm | 1025 mm | 1041 mm | 1056 mm | 1065 mm | 1093 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 675 mm | 703 mm | 733 mm | 766 mm | 812 mm | 853 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Outlook is a Diamondback Outlook model. Diamondback launched 1 bike of this model so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Outlook components
Fork
This bike has the SunTour fork installed. The fork’s travel is 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When it comes to wheels, the Outlook bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Outlook is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
