Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 130mm -
Fork Fox Performance Float 36
-
Groupset NX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Release 27.5, Monocoque Carbon Front and Rear Triangle, 130mm Travel, Level Link Suspension Platform, Euro Standard Threaded BB, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube, Post Mount Disc Tabs
Suspension Fork
Fox 36 Performance Float, 27.5", 150mm Travel, Grip 3 Position Damper, Rebound Adjust, 1.5" Tapered Steerer, 110x15mm Thru-axle, 44mm Offset
Rear Shock
Fox Float DPS EVOL LV, Performance, 3 Position Lever, 200x57mm, 22.2mm Eyelet Width
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12 Speed
Cassette
SRAM PG-1230 Eagle, 12 Speed, 11-50T
Crank
SRAM Descendant 6K Eagle w/32T Direct Mount
Bottom Bracket
SRAM DUB Outboard Bearing
Chain
SRAM NX Eagle, 12 Speed
Pedals
DB CNC Platform, Sealed Cartidge Bearing w/Replaceable Pins
Wheels
Front Hub
Novatec SL-Team, 32h Aluminum Boost 110x15mm Thru-axle, Sealed Cartridge Bearing
Rear Hub
Novatec SL-Team, 32h Aluminum, 148x12mm Thru-axle, Sealed Cartridge Bearing
Rims
Diamondback Blanchard 28R, Taped for Tubeless, 32h
Spokes
14g Stainless Steel
Tires
Maxxis Minion DHF 27.5x2.3" EXO, TR (Tubeless Ready), Folding / Maxxis Minion DHR 27.5x2.3" EXO, TR (Tubeless Ready), Folding
Brakes
Brakes
SRAM G2 R, 4 Piston w/180mm Front / 180mm Rear Centerline Rotors
Brake Levers
SRAM G2 R
Cockpit
Stem
Factor Components F355, 35mm Reach, 35mm Bar Bore
Handlebar
DB35 Aluminum 780mm Wide, 15mm Rise, 35mm Bar Bore
Grips
Ergon GE10 Evo Lock-On
Headset
FSA No. 57 Sealed Cartridge
Seat
Saddle
WTB Volt Chromoly
Seatpost
KS Rage-I, Internal Dropper, 31.6 w/Westy 1x Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.537 mm | 1.438 mm | 1.392 mm | 1.337 mm | 1.294 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 682 mm | 708 mm | 735 mm | 761 mm | 788 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 110 mm | 110 mm | 111 mm | 110 mm | 109 mm |
| Stack | 584 mm | 584 mm | 597 mm | 603 mm | 612 mm |
| Reach | 380 mm | 406 mm | 429 mm | 451 mm | 473 mm |
| Top Tube Length | 557 mm | 585 mm | 610 mm | 635 mm | 660 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 388 mm | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1107 mm | 1133 mm | 1160 mm | 1186 mm | 1213 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm | 14 mm | 14 mm |
| Standover Height | 739 mm | 739 mm | 740 mm | 743 mm | 749 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm | 150 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
