Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Factory Float 36
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM G2 RS Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Release 27.5, Monocoque Carbon Front and Rear Triangle, 130mm Travel, Level Link Suspension Platform, Euro Standard Threaded BB, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube, Post Mount Disc Tabs
Suspension Fork
Fox 36 Factory Float, 27.5", 150mm Travel, GRIP2, 3 Position Damper, Rebound Adjust, 1.5" Tapered Steerer, 110x15mm Thru-axle
Rear Shock
Fox Factory Float DPS, 3 Position Lever w/Open Mode Adjust, EVOL LV, 200x57mm, 22.2mm Eyelet Width
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed
Front Derailleur
MRP XCG V2 Aluminum Bash Guard, 32T, ISCG-05
Shift Levers
SRAM GX Eagle, 12 Speed
Cassette
SRAM XG-1275 Eagle, 12 Speed, 10-50T
Crank
SRAM Descendant 7K Eagle w/32T Direct Mount
Bottom Bracket
SRAM DUB Outboard Bearing
Chain
SRAM GX Eagle, 12 Speed
Pedals
DB CNC Platform, Sealed Cartidge Bearing w/Replaceable Pins
Wheels
Front Hub
Novatec XD641, 28h Aluminum110x15mm Boost Thru-axle, Sealed Cartridge Bearing
Rear Hub
Novatec XD642, 28h Aluminum Boost 148x12mm Thru-axle, 4 Sealed Cartridge Bearing, w/CNC Disc Mount, XD Cassette Body
Rims
E*Thirteen LG1 EN Plus, w/TRS Plus Aluminum 27.5", 30mm internal width, 28h, Taped for Tubeless
Spokes
2.0/1.8/2.0 Butted Stainless Steel
Tires
E*Thirteen TRS Race All-Terrain, Tubeless Ready, 27.5x2.4"
Brakes
Brakes
SRAM G2 RS
Brake Levers
SRAM G2 RS
Cockpit
Stem
Factor Components F355, 35mm Reach, 35mm Bar Bore
Handlebar
Race Face Turbine R, 780mm Wide, 20mm Rise, 35mm Bar Bore
Grips
Ergon GE10 Evo Lock-On
Headset
FSA No. 57 Sealed Cartridge
Seat
Saddle
WTB Volt Chromoly SL
Seatpost
KS Rage-I, Internal Dropper, 31.6 w/Westy 1x Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.403 mm | 1.354 mm | 1.307 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 689 mm | 714 mm | 740 mm | 766 mm |
| Rake | 47 mm | 47 mm | 48 mm | 47 mm |
| Trail | 95 mm | 95 mm | 94 mm | 95 mm |
| Stack | 599 mm | 599 mm | 608 mm | 617 mm |
| Reach | 402 mm | 427 mm | 449 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | 660 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1134 mm | 1159 mm | 1185 mm | 1211 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 775 mm | 784 mm | 791 mm | 804 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 162 cm | 169 cm | 176 cm | 187 cm |
| Rider Max Height | 172 cm | 179 cm | 189 cm | 198 cm |
