Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 140mm -
Travel Rear 110mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes SRAM G2 R Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 189cm
XL
187cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Yowie 29, Monocoque Carbon Front and Rear Triangle, 110mm Travel, Level Link Suspension Platform, Press-Fit, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube, Post Mount Disc Tabs
Suspension Fork
Fox 34 Performance Float Grip 3, 130mm of Travel
Rear Shock
Fox DPS Performance Elite Float
Drivetrain
Rear Derailleur
SRAM GX Eagle. 12 Speed, Long Cage
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG-1275, 12 Speed, 10-52 Tooth
Crank
SRAM GX Eagle
Bottom Bracket
SRAM DUB PF30
Chain
SRAM NX Eagle
Pedals
DB Aluminum Platform w/Replaceable Pins
Wheels
Front Hub
Novatec D791SB-B15, 28h Aluminum110x15mm Boost Thru-axle, Sealed Cartridge Bearing
Rear Hub
Novatec D902SB-B12-S11, 28h Aluminum Boost 148x12mm Thru-axle, 4 Sealed Cartridge Bearing, w/CNC Disc Mount, XD Cassette Body
Rims
E*Thirteen TRS Plus, w/TRS Plus Aluminum 27.5", Taped for Tubeless, 27mm internal width, 28h
Spokes
2.0/1.8/2.0 Butted Stainless Steel
Tires
Maxxis Rekon 29x2.4" Front / Rekon Race 29x2.25" Rear, both Tubeless Ready
Brakes
Brakes
SRAM G2 R
Brake Levers
SRAM G2 R
Cockpit
Stem
DB35 Aluminum 35mm Reach, 35mm Bar Bore
Handlebar
DB35 Aluminum 780mm Wide, 20mm Rise, 35mm Bar Bore
Grips
Ergon GE10 Evo Lock-On
Headset
FSA IS-2/42/ACB
Seat
Saddle
WTB Volt Chromoly SL
Seatpost
KS LEV Integra Internal Dropper, w/SouthPaw Remote, 31.6mm, TRAVEL XS- 100MM, S - 125MM, MED - 150MM, L - 175MM, XL -175MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.403 mm | 1.354 mm | 1.307 mm |
| Bottom Bracket Height | 348 mm | 348 mm | 348 mm | 348 mm |
| Front Center | 689 mm | 714 mm | 740 mm | 766 mm |
| Rake | 47 mm | 47 mm | 48 mm | 47 mm |
| Trail | 103 mm | 103 mm | 102 mm | 103 mm |
| Stack | 599 mm | 599 mm | 608 mm | 617 mm |
| Reach | 402 mm | 427 mm | 449 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | 660 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1134 mm | 1159 mm | 1185 mm | 1211 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 775 mm | 784 mm | 791 mm | 804 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 169 cm | 176 cm | 187 cm |
| Rider Max Height | 172 cm | 179 cm | 189 cm | 198 cm |
