Eddy Merckx Strasbourg Aluminium Shimano GRX600 1x12sp 2024
2024 Road
Estimate price |
2,442$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Strasbourg A 7E7/size M/SBA84As
Suspension Fork
Forza Oryx Disc, TA 12x100mm
Drivetrain
Rear Derailleur
Shimano GRX 800, 12sp, Medium Cage (45T)
Cassette
Shimano SLX M7100 12s 10-45 Hyperglide+
Crank
172,5, 40T
Pedals
Not included **
Wheels
Rims
Front: 4ZA Norte G DB F 24TL -3BF V2- NO STI, Rear: 4ZA Norte G DB R 24TL -3BF V2 MS12- NO STI
Tires
Vittoria Terreno Dry, 700x38c
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Forza Stratos, 110 mm, Black Glossy
Handlebar
4ZA Stratos Gravel 420/480
Seat
Saddle
Selle San Marco Shortfit Wide
Seatpost
Forza Stratos, 15mm Offset, 350mm, 27,2mm, Black Glossy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.452 mm | 1.485 mm | 1.521 mm | 1.552 mm | 1.587 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 599 mm | 610 mm | 620 mm | 640 mm | 651 mm |
| Rake | 51 mm | 50 mm | 49 mm | 49 mm | 45 mm |
| Trail | 69 mm | 71 mm | 68 mm | 68 mm | 73 mm |
| Stack | 543 mm | 563 mm | 587 mm | 616 mm | 641 mm |
| Reach | 374 mm | 379 mm | 386 mm | 397 mm | 404 mm |
| Top Tube Length | 525 mm | 540 mm | 565 mm | 585 mm | 600 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 465 mm | 495 mm | 525 mm | 555 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 115 mm | 135 mm | 160 mm | 190 mm | 215 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1018 mm | 1029 mm | 1039 mm | 1060 mm | 1071 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 478 mm | 509 mm | 535 mm | 562 mm | 578 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
