Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 166mm -
Fork RockShox ZEB Ultimate
-
Groupset XT -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BT-E8036, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Epocalypse 166mm of travel, UD carbon, Full internal cable routing, SB+ 157mm rear spacing
Suspension Fork
Rockshox ZEB Ultimate, 29", Charger 2.1 RC2, 170mm Travel, 44mm Offset
Rear Shock
Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, ML 320
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano XT SL-M8100-R, I-Spec
Cassette
Shimano XT CS-M8100-12, 10-51T
Crank
Shimano XT FC-M8150, 170mm
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano XT CN-M8100, 118 Links
Wheels
Rims
Industry Nine Enduro S Hydra, Internal rim width: 30.5mm, Hub Width 110x15mm, Centerlock
Tires
Maxxis Minion DHF EXO TR, 29x2.5 WT
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Evil 12 Gauge, Clamp: 35mm, Length: 45mm
Handlebar
Evil Energy Bar, UD Carbon, Rise: 35mm, Clam 35mm, Width: 780-810mm, Backsweep: 8, Upsweep: 5
Grips
Evil Palmela Handerson lock-on
Headset
Cane Creek 40 Series ZS Integrated Tapered Headset - Cups: ZS44/28.6 (Upper) and ZS62/40(Lower), Bearing: 36 x 45 - 41mm (Upper) and 36 x 45 - 52mm (Lower) ZN40 Zinc Coated, Crown Race: 28.6mm x 36 Integrated (Upper) and 40mm x 36 Press Fit (Lower)
Seat
Saddle
WTB Volt Medium, Width: 142mm, Chromoly Saddle
Seatpost
Bike Yoke Revive, S:125mm, M: 160mm, L:185m XL: 185mm
Motor & Battery
Motor
Shimano DU-EP800
Battery
Shimano BT-E8036, 630Wh
Charger
Shimano Charger EC-8004-2 (USA/Canada)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.39 mm | 1.36 mm | 1.32 mm |
| Bottom Bracket Height | 355 mm | 355 mm | 355 mm | 355 mm |
| Front Center | 776 mm | 797 mm | 822 mm | 847 mm |
| Rake | 43 mm | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 633 mm | 642 mm | 654 mm | 665 mm |
| Reach | 445 mm | 462 mm | 482 mm | 502 mm |
| Top Tube Length | 606 mm | 623 mm | 644 mm | 666 mm |
| Seat Tube Angle | 75.6 ° | 75.6 ° | 75.6 ° | 75.6 ° |
| Seat Tube Length | 390 mm | 425 mm | 460 mm | 495 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 104 mm | 114 mm | 127 mm | 139 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1224 mm | 1245 mm | 1270 mm | 1295 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 734 mm | 734 mm | 734 mm | 742 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Epocalypse XT is part of the Evil E Epocalypse model. There are 2 e-bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, this doesn’t mean that if you spend less money on an Enduro e-bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Evil Epocalypse XT price was 9999$. Comparing this to the average Enduro e-bike price, we see that the price is 108.97% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Epocalypse XT components
Fork
Evil Epocalypse XT 2023 e-bike is equipped with the RockShox ZEB Ultimate fork, and has 170mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this e-bike is Rockshox Super Deluxe Coil Ultimate, with a travel distance of 166mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Epocalypse XT model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Evil Epocalypse XT is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Evil Epocalypse XT includes a dropper post. Therefore, climbing or descending will be a breeze.
