factor LS Frameset Premium 2025
2025 Road
Estimate price |
3,999$
Weight | 0.85 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Factor Toray® & Nippon Graphite® Pan-Based Fiber
Suspension Fork
Factor LS carbon
Drivetrain
Bottom Bracket
CERAMICSPEED T47A BB - SHIMANO
Brakes
Brakes
Disc
Cockpit
Headset
FSA 1-1/8? upper and 1-3/8? lower bearings
Seat
Seatpost
27.2 Round, post not included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.425 mm | 1.447 mm | 1.478 mm | 1.492 mm | 1.509 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 582 mm | 590 mm | 597 mm | 612 mm | 627 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 60 mm | 60 mm | 59 mm | 59 mm | 59 mm |
| Stack | 530 mm | 547 mm | 566 mm | 585 mm | 605 mm |
| Reach | 372 mm | 378 mm | 383 mm | 392 mm | 401 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 481 mm | 507 mm | 527 mm | 552 mm |
| Head Tube Angle | 71.5 ° | 71.9 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 990 mm | 998 mm | 1005 mm | 1020 mm | 1035 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 748 mm | 772 mm | 789 mm | 809 mm | 831 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
